Description
| TECHNICAL SPECS OF AK150 | ||
| Ref. No. | Items | Specs |
| 1 | Overall dimensions (L×W×H): | 2030×760×1090 (mm) |
| 2 | Wheelbase: | 1330mm |
| 3 | Ground clearance: | 280mm |
| 4 | Dry weight: | 128Kg |
| 5 | Max loading capacity: | 150Kg |
| 6 | Max speed: | ≧95Km/h |
| 7 | Brake system (FR/RR): | Disc/disc |
| 8 | Tire sizes (FR; RR): | 80/90-17; 120/80-17 |
| 9 | Fuel tank capacity: | 12L |
| 10 | Displacement (cc): | 149cc |
| 11 | Engine type: | Single-cylinder, air-cooled, 4-stroke |
| 12 | Starting system: | Electric/Kick |
| 13 | Ignition: | CDI |
| 14 | Bore × stroke: | 62.0×49.5mm |
| 15 | Max power: | 8.2KW/8500r/min |
| 16 | Max torque: | 9.8/7000r/min |
| 17 | Fuel consumption: | 1.8L/100km |
| 18 | Container loading quantity: | 96 units/40ft HQ (SKD) |
