CUBS-UD110/125

CUBS model UD110/125 inspired by SUZUKI UT series, with 110/125cc engine. One of the most classical models in motorcycle industry, especially in Africa and Latin America markets. With aluminum wheels, drum/drum brakes, rear shock absorbers.

Categories: ,
Description

Product advantages:

  1. Modeling: The sharp appearance of the Blade Warrior and the smooth body lines show sporty fashion. The front of the model rises, the side covers strike like sharp blades, and the polygonal taillights create a strong sense of technology and futurism.
  2. Super Power: Maximum power: 6.5kW/7500rpm and maximum torque: 8.7 N.m/6500rpm, equipped with a revolutionary 114/125cc UT engine, the power surpasses that of traditional 125cc curved beam model. Starting fiercely, accelerating quickly, and carrying cargo more effectively, on long and steep slopes like walking on flat ground;
  3. Open front compartment+USB charging interface: Specially designed front compartment for easy access and storage of mobile phones and other personal items; The 5V 2A USB charging interface is within reach, so you no longer have to worry about your phone running out of battery when going out.
  4. Stable and comfortable driving experience: Comfortable driving posture, with both feet easily landing on the ground. Equipped with five adjustable rear shock absorbers, the shock absorbers can be adjusted to a comfortable position for passengers with family, heavy cargo, or single riders.
  5. LED Headlight: The brightness of the headlights is stable, even when driving slowly and slowly on dim roads, the light remains bright as before, avoiding the bad situation of AC headlights becoming dim when decelerating, and ensuring safety.
  6. Electric/Foot Dual Start: Double protection, no worries about emergency start-up.
  7. Turn signal sound: Remind to turn off the turn signal in a timely manner to eliminate safety hazards.



Technical Parameter:

TECHNICAL SPECS OF UD110/125
Ref. No. Items Specs
1 Model UD
2 Dimension (L*W*H) (mm): 1930×710×1090mm
3 Wheelbase (mm): 1230
4 Ground Clearance (mm): 245
5 Engine Type: Air-cooled, single cylinder, 4-stroke
6 Displacement (cc): 114/125cc
7 Start Method: Electric/Kick Start
8 Max Power (KW/rpm): 6.5KW/7500r/min; 8.2KW/7500r/min
9 Max Torque (N.m/rpm): 8.7N.m/6500r/min; 10.3N.m/6500r/min;
10 Max Speed (km/h) ≧80;≧85;
11 Net Weight (KG): 103
12 Max Payload Mass (KG): 150
13 Brake types (FR/RR) Drum/ Drum
14 Tire Type (FR/RR): 70/90-17; 80/90-17
15 Ignition: CDI
16 Fuel Tank Capacity (L): 3.9L
17 Container Loading Capacity: 126units/40ft HQ (SKD packing)

196units/40ft HQ (SKD packing)
